How to Replace the Google Pixel 8 Pro LCD Screen: Step-by-Step Guide

Why Replace Your Google Pixel 8 Pro LCD?

A damaged LCD can hinder your phone’s functionality, from cracked glass to unresponsive touch or dead pixels. Replacing the LCD restores clarity, touch response, and features like fingerprint sensors or foldable features. This guide uses a screen assembly with frame for easier installation.

Tools and Supplies Needed

• Replacement Google Pixel 8 Pro LCD screen with frame
• Phillips screwdriver
• Suction cup
• Plastic opening pick
• Tweezers
• Heat source (iOpener, hairdryer, or heat gun)
• Adhesive strips for reassembly
• Spudger
• Microfiber cloth
• Phillips screwdriver
• Suction cup
• Plastic opening pick
• Tweezers
• Heat source (iOpener, hairdryer, or heat gun)
• Spudger

Safety Precautions

• Drain the battery below 25% to reduce fire risk from lithium-ion batteries.
• Work in a clean, well-lit area to avoid losing small parts.
• Use a heat source cautiously to avoid damaging the display or battery.
• Handle connectors gently to prevent bending pins.
• Back up your data before starting, as a precaution.

Step-by-Step Instructions

1. Power Off the Phone: Turn off the Google Pixel 8 Pro. Hold the power button and select 'Power off' to shut down the device completely. Drain the battery below 25% to reduce fire risk.
2. Remove the SIM Card Tray: Insert a SIM card ejector tool into the hole at the side of the phone to eject the SIM tray. Remove and set aside the tray.
3. Remove the Back Cover: Heat an iOpener or use a hairdryer to warm the edges of the back cover for two minutes to soften the adhesive. Attach a suction cup, pull gently, and insert a plastic opening pick to separate the back cover.
4. Remove the Wireless Charging Coil and Loudspeaker: Use a Phillips screwdriver to remove screws securing the NFC antenna and charging coil, and the loudspeaker. Pry up the wireless charging coil press connector with a spudger and remove the coil and loudspeaker.
5. Disconnect the Battery and Interconnect Cables: Use a spudger to disconnect the battery press connector and interconnect cables from the motherboard and charging board. Remove the interconnect cables from the frame.
6. Remove the Charging Board: Remove screws securing the charging board. Pry up the board with a spudger and lift it out of the frame.
7. Remove the Screen Assembly: Disconnect the screen press connector from the motherboard using a spudger. Remove the screen cable and lift the damaged screen assembly (including frame and battery) from the device.
8. Install the New LCD Assembly: Place the new LCD screen assembly (with frame) into the device. Reconnect the screen press connector to the motherboard, ensuring a secure connection.
9. Reinstall the Charging Board: Place the charging board back into its recess and secure it with the screws.
10. Reconnect Cables and Reinstall Components: Reconnect the battery and interconnect cables. Reinstall the wireless charging coil and loudspeaker, securing them with their respective screws.
11. Reattach the Back Cover: Apply new adhesive strips to the frame. Align and press the back cover into place. Reinsert the SIM card tray.
12. Test the Repair: Power on the phone and test the display for touch responsiveness, color accuracy, fingerprint sensor, and camera functionality. Ensure there are no dead pixels or display issues.

Frequently Asked Questions

Conclusion

Replacing the Google Pixel 8 Pro LCD screen is a complex but achievable DIY project with the right tools and patience. Wireless World’s guide ensures you restore your device’s stunning display, but proceed cautiously to avoid damaging components. For professional repairs, contact a certified technician or visit Motorola Support.
